Description
Cast Iron Electric Hot Plate EKCh-145 mm (1000 W / 1.0 kW) Electron
Original cast iron electric hot plate (EKCh) with a diameter of 145 mm and a power of 1000 W (1.0 kW) from the Electron brand is designed for installation in domestic electric cookers, hobs, and tabletop stoves. Made of heat-resistant high-strength cast iron with a special anti-corrosion coating. Internal heating coils are pressed into a high-quality ceramic insulator, which guarantees fast heating, uniform heat distribution, and long service life.
Key Advantages and Features:
- High-quality cast iron and protective rim: The cast iron body is resistant to mechanical damage and temperature fluctuations, while the protective galvanized stainless steel rim prevents spilled liquids from getting under the stove's working panel.
- Universal connection: The terminal block with screw clamps for 4 contacts allows the hot plate to be connected to both smooth stepless power regulators (energy regulators) and standard 7-position step switches.
- Reliable mounting: A central threaded stud with a diameter of 8 mm (M8) ensures tight fixation of the hot plate in the mounting seat of the stove's working surface.
- Energy efficiency and heat capacity: The massive cast iron disk retains heat for a long time after the power is turned off, allowing dishes to reach readiness while saving electricity.
Signs of Electric Hot Plate Failure:
- The hot plate has stopped heating completely or only heats up at certain switch positions (burnout of one of the internal coils).
- The surface of the cast iron disk is cracked, swollen, or shows signs of deep corrosion.
- When the hot plate is turned on, the circuit breaker or RCD trips (insulation breakdown of the heating element to the body).
Compatibility and Application:
Suitable for most domestic electric stoves of domestic and foreign production with a mounting socket for a diameter of 145 mm (14.5 cm):
- Nord electric stoves: EP, ED series models, etc.
- Lysva & Greta electric stoves: All classic models with cast iron disks.
- Rainford, Elektra, Mechta, ZVI, Druzhkovka, Cezaris, De Luxe electric stoves, etc.
Technical Specifications:
| Parameter | Value / Specification |
|---|---|
| Brand / Manufacturer | Electron |
| Part type | Cast iron electric hot plate (EKCh / disk) |
| Working diameter of the heating surface | 145 mm (14.5 cm) |
| Rated power | 1000 W (1.0 kW) |
| Operating voltage | 220 – 230 V / 50 Hz |
| Regulator type | For smooth (stepless) or 7-position step switch |
| Connection type | Screw terminal block (4 contacts) |
| Mounting stud thread | M8 (diameter 8 mm) |
| Body / rim material |
