Description
90XL-8 Timing Belt (45 teeth, 8 mm width, XL pitch)
90XL-8 timing drive belt (8 mm width) is designed to transmit torque from the electric motor to the drive shaft in electric planers, sanders, sewing machines, small machine tools, and other power tools. It is made of wear-resistant neoprene with a reinforcing fiberglass cord, which ensures minimal stretching and high resistance to abrasion at high speeds.
Key Advantages and Features:
- Zero Slippage: Trapezoidal XL standard teeth guarantee precise engagement with pulleys and smooth power transmission.
- Fiberglass Reinforcement: The internal power cord maintains a constant length and prevents the belt from stretching under operating loads.
- Wear and Temperature Resistance: The rubber compound retains elasticity when heated and is resistant to dust, wood chips, and technical oils.
Compatibility and Model Range:
The **90XL / 90XL-8** standard belt is used in the following equipment and tool models:
- Electric Planers: Rebir IE-5708 (early modifications/drives), Interskol P-82 (certain series), Stern EP-600 / EP-750, Einhell EH-82, Ferm FPB-820, Kinzo, Profi, DWT, and similar Chinese planers requiring a 228 mm belt.
- Sanders: Household-grade belt sanders with an 8 mm belt width.
- Sewing Machines and Sergers: Drives for household and semi-industrial sewing machines (Veritas, Singer, Seagull, Radom, Chaika with external XL drive).
- CNC and 3D Printers: Positioning units and axis drives for desktop milling and laser machines.
Technical Specifications:
| Parameter | Value / Specification |
|---|---|
| Part Type | Timing Belt |
| Marking / Standard | 90XL-8 (90XL-031) |
| Number of Teeth | 45 teeth |
| Tooth Pitch | 5.08 mm (0.200" / XL pitch) |
| Pitch Length (L) | 228.6 mm (9.0 inches) |
| Belt Width | 8 mm |
| Tooth Profile | Trapezoidal (XL) |
| Material | Neoprene with fiberglass cord |
Package Includes:
- 90XL-8 Timing Belt ā 1 pc.
