Description
V-belt Z730 for Fresh, Saturn washing machines 700-730 (0700E), profile 0(Z), outer length 745 mm, width 9.5 mm
V-belt drive belt Z730 / 0700E (profile Z / O) ā reliable power transmission
The Z(O) profile V-belt marked Z730 (alternative designation 0700E / O700E) is a standardized transmission element designed to transmit torque from the motor pulley to the working units in various household, industrial, and agricultural machinery. The belt features high elasticity, resistance to stretching, and reliable grip with the pulleys.
Key Advantages and Features:
- High wear resistance: Made of durable cord fabric and oil-and-gasoline-resistant rubber compound, ensuring a long service life even under heavy loads and temperature fluctuations.
- Optimal Z / O profile: Features a classic trapezoidal cross-section (top width 10 mm, height 6 mm), providing reliable wedge grip with the pulley walls without slipping.
- Universal interchangeability: The markings Z730 and 0700E (O700E) denote the same V-belt size according to various standards (GOST, ISO, DIN), making it easy to find an equivalent during repair.
- Wide range of applications: Used in semi-automatic and automatic washing machines, concrete mixers, small-sized machine tools, compressors, walk-behind tractors, and other equipment.
Technical Specifications:
| Parameter | Value / Characteristic |
|---|---|
| Belt type | Smooth V-belt (classic) |
| Cross-section profile | Z (Russian equivalent ā profile O) |
| Main marking | Z 730 / Z730Li / 10x730 |
| Alternative marking | 0700E / O-700E / O-730 |
| Top width | 10 mm |
| Belt height (thickness) | 6 mm |
| Inner length (Li) | 730 mm |
| Pitch/datum length (Lw / Ld) | approx. 752 mm |
| Material | Wear-resistant rubber, power cord made of polyester/aramid |
Package Includes:
- V-belt drive belt Z730 (0700E) ā 1 pc.
Installation Tip: When replacing the drive belt, be sure to check the pulley alignment and adjust its tension. The belt should not sag or be overtightened ā optimal tension will prevent premature wear of the shaft bearings and the belt itself.
