Description
▪ Pumped liquid: clean, non-viscous, non-aggressive liquids containing no solid particles or fibres
▪ Hydrogen index pH 7.0-9.5
▪ Maximum glycol content: 50%
▪ Maximum lower and upper temperature values of the pumped liquid: from -10°C to + 110°C
▪ Maximum ambient temperature + 40°С
▪ Maximum working pressure: 1 MPa (10 bar)
▪ To avoid cavitation noise, the suction pressure must be at least 1.5 m of water column at a temperature of + 90 °C.
Design characteristics
▪ Monoblock horizontal row pumps with one impeller
▪ Pump chamber body made of cast iron
▪ The closed-type centrifugal working wheel is made of heat-resistant polymer.
▪ Metal-ceramic shaft
▪ Radial plain bearings made of metal ceramics
▪ Protective stator sleeve made of stainless steel AISI 304
▪ AISI 304 stainless steel reflector
▪ Aluminum engine housing
Characteristics
- Barcode 4823121302893
- Warranty period, months: 12
- The operating principle is centrifugal.
- Rotor type: wet
- Power voltage: 220 V, 50 Hz
- Power consumption, W: 160
- Length, mm: 180
- Threaded connection type of branch pipes
- Inlet connection: G1½-B
- Outlet: G1½-B
- Maximum pressure, m: 8.0
- Maximum capacity, m³/h: 5.40
- Liquid type: pure water
- Maximum temperature of pumped liquid °C: 110
- Minimum temperature of pumped liquid, °C: -10
- Maximum particle size, mm: 0.2
- Number of speeds: 3
